1) The sherical hinged routel: It can reduce the stress concentration of the glass holes caused by the glass deformation.

2) Heat insulation routel: Adopting the bridge cut off theory to the design. It can reduce the heat loss of the interior and the surface sweating of routel.
3) Outside installation routel: It mainly used to the condition when there is not enough room for installation or it is not convenient to install from the interior, but easy to install from the outside.
4) The dust-proof routel: The dust-proof cover can prevent the dust from entering the rotating part of the routel to avoid affecting its normal function.
5) The routel applies to the hollow glass (laminated glass): The advantage of this routel.
** Avoiding the possibility of water seepage of the routel.
** The surface of the glass curtain wall will be more beautiful.
6) The routel with the adjustable off center. To adjust the off center magitude of the routel throught turning the aluminium washer and the base.

The permitted load for connector which is used for point supporting glass screen wall.

DETAIL COMPOSITION OF 316 STAINLESS STEEL

NI - 8.1
CR - 18.08
FE - 72
AI - 0.0047
C - 0.058
Mn - 0.9
Si - 0.43
P - 0.028
S - 0.007
